// MODELS

A Great Selection of Outstanding Solutions

Every Model a Star

We offer our customers a selection of high-quality shovel separators that are easy to install and can be used in diverse preparation applications. Depending on the blade volume needed, the desired screen surface or the required number of screen shafts, you will get the right model for attachment to your excavator or wheel loader.

OUR MODELS

Large Shovel, Fine Result
The Right Blade Separator for Your Demand

The shovel separators from Neuenhauser have straight side walls inside and out, and do not need any interfering chain cases. The vertical screen shafts, of which four to ten can be used, ensure very good mixing and loosening of the materials. The shovel separators are extremely practical for use at construction sites, landfills and in sand or earth works. They are outstandingly suitable for soil preparation, composting and sewer construction.

  • Shovel width = working width
  • Low stocks, leading to the least possible bearing stress
  • Long screen route
  • Beaters hardened and tempered
  • Optional with special hard surfacing



The following additional options are available for the Neuenhauser shovel separators:

  • The X-module is used to reverse the direction of rotation of the wave packets
  • The HD version has a reinforced shovel base and side wear strips

Technical Data

Our experienced and competent employees will gladly help you with any questions concerning our blade separators. Contact us directly and use our customer-oriented service.

Length1,230 mm
Width1,390 mm
Height1,400 mm
Weight without adapter plateapprox. 1,420 kg
Screening area1.0 m²
Quantity of shafts4
Rotation cruiseapprox. 200 rpm
Shovel volume1.3 m³
Quantity of drive motors2
Installed drive power58 kW
Requirements for the carrier
Oil pressuremax. 250 bar
Flow rate130-225 l / min
Shaft design
Separation distance30/40 or 60 mm
Version
Standardfor screening and treatment of solid soils
Longfor screening and treatment of very solid soils, sludge and compost
Model B-4 Model B-4

[Translate to Englisch:] B-6

Length1,740 mm
Width1,390 mm
Height1,400 mm
Weightwithout adapter plateapprox. 1,850 kg
Screening area1.4 m²
Quantity of shafts6
Rotation cruiseapprox. 200 rpm
Shovel volume1.8/2.2 m³
Quantity of drive motors2
Installed drive power58 kW
Requirements for the carrier
Oil pressuremax. 250 bar
Flow rate130-225 l/min
Shaft design
Separation distance30/40 or 60 mm
Version
Standardfor screening and treatment of solid soils
Longfor screening and treatment of very solid soils, sludge and compost
Model B-6 Model B-6

[Translate to Englisch:] B-8

Length2,230 mm
Width1,390 mm
Height1,420 mm
Weight without adapter plateapprox. 2,255 kg
Screening area1.8 m²
Quantity of shafts8
Rotation cruiseapprox. 200 rpm
Shovel volume2.3/2.8 m³
Quantity of drive motors2
Installed drive power58 kW
Requirements for the carrier
Oil pressuremax. 250 bar
Flow rate130-225 l/min
Shaft design
Separation distance30/40 or 60 mm
Version
Standardfor screening and treatment of solid soils
Langfor screening and treatment of very solid soils, sludge and compost
Model B-8 Model B-8

[Translate to Englisch:] B-10

Length2,720 mm
Width1,390 mm
Height1,420 mm
Weight without adapter plate2,775 kg
Screening area2.2 m²
Quantity of shafts10
Rotation cruiseapprox. 180 rpm
Shovel volume2.9/3.6 m³
Quantity of drive motors2
Installed drive power100 kW
Requirements for the carrier
Oil pressuremax. 250 bar
Flow rate300-380 l/min
Shaft design
Separation distance30/40 or 60 mm
Version
Standardfor screening and treatment of solid soils
Longfor screening and treatment of very solid soils, sludge and compost
Model B-10 Model B-10
